Xantrex 50Ah, 24V Lithium Iron Phosphate Trolling Motor Battery with BMS
Xantrex 50Ah, 24V Lithium Iron Phosphate Trolling Motor Battery with BMS
Couldn't load pickup availability
More Power in Less Space
The Xantrex Lithium-Ion Phosphate (LiFePO4) battery used UL1642 certified cells. Equipped with redundant safety features, it is the safest in the market today. Specifically designed to withstand the harsh operating environments of mobile and marine applications, the battery lasts up to 4,000 cycles compared to a traditional lead acid or AGM battery, which typically lasts 400-500 cycles. It offers exceptional power density and is also available with a heating blanket option if the installation is outside the main cabin.
Sleep Mode : Xantrex Lithium-Ion Phosphate batteries self-discharge at 12.5% State of Charge (SOC) per month during regular use. After 10 consecutive days of inactivity, the battery switches to a low power mode, reducing the self-discharge rate to 3% SOC per month. Any charge or discharge activity will reactivate the battery, resetting the 10-day counter. This extends the battery life during periods of non-use
Environmental Specs
| 24V 50Ah Lithium-Ion Battery | |
| Charging Temperature Range | 0 - 55°C (32°F - 131°F) |
| Discharging Temperature Range | -20 - 65°C (-4°F - 149°F) |
| Storage Period 1 Month | -10 - 45°C (14 -113°F) 5-75%RH |
| Storage Period 6 Months | 0 - 30°C (32 - 86°F) 5-75%RH |
Mechanical Specs
| 240Ah Lithium-Ion Battery | |
| Dimensions | 10.2” x 6.6” x 8.2” (260mm x 168mm x 209mm) G27 |
| Weight | 25.4lbs (11.5kg) |
| Battery Terminals | M8 x 1.25 |
| Carrying Capability | Two Foldout Handles |
| Mounting Orientation | Horizontal or Vertical |
Relevant documentations:
Applications
Applications
- Recreational Vehicles
- Heavy Duty Trucks
- Work Trucks
- Marine
- Specialty Vehicles
